LG LAS018DB2EF
LAS Fine-pitch Series
LG LAS018DB2EF
1920 X 1080, 600 Nit, DVLED Standard 1.89mm pitch FHD Bundle, 3-Year Warranty#LAS018DB2EF
Our Price: Request a Quote
Click here to jump to more pricing!
Please Note: All Prices are Inclusive of GST
LAS Fine-pitch Series
LG LED Signage - Indoor
The LAS Fine-pitch series offers a unit case with 16:9 aspect ratio, as well as light-weight cabinet design and front serviceability for easy installation and maintenance.
Cable-less Stackable Design
Stackable unit cases and signal connector enable easy installation.
16:9 Aspect Ratio
With 16:9 aspect ratio, you can enjoy existing content without additional editing.
Easy-handling Lightweight Unit Case
Its lightweight unit cases enable easy installation and prevent damage.
Signal/Power Redundancy
The additional controller and power unit prevents a screen blackout and offers stable power. (Optional)
Front Serviceability
The product offers front access, freeing customers from needing rear access space.
Uniform Picture Quality with Accurate Colors
Our strictly managed production enables us to provide seamless content and vivid colors without distortion.
RoHS Certified Safe Product
With RoHS certified, all LG LED signage models are eco-friendly while not using harmful materials
Features:
Cableless Installation and Clean Design
Unit cases are stackable, with sockets on the top and bottom that align. Thanks to the built-in power and signal connector protruding from the top, there is no need for wiring between unit cases. With easy installation and virtually seamless appearance, this design eliminates the need for cables or additional space.
16:9 Aspect Ratio Optimized for FHD/UHD Content
Each unit case uses a 16:9 aspect ratio, the same most commonly used in displays for FHD and UHD content. This allows you to enjoy existing content without additional editing.
Front Serviceability
The product offers front access, freeing customers from needing rear access space.
Reliable Operation with Signal/Power Redundancy
With an additional controller and power unit, a back-up controller activates if a signal transmission error occurs, preventing a screen blackout error (Signal Redundancy*). The product also offers Power Redundancy*. Two power units are provided in every LED unit; one activates to provide power when the other fails.
*Optional.
Uniform Picture Quality
Every step from production is strictly managed, while factory calibration ensures consistent quality between the LED units. The display provides seamless content with high brightness uniformity.
Vividness with Color Accuracy
LG's rigorous quality standards also make LG LED signage reproduce accurate colors, vividly displaying the original colors of objects without distortion.
Specifications:
| LAS018DB2-F Specifications | |
|---|---|
| Physical Parameters | |
| Pixel Configuration | 3 in 1 SMD |
| Pixel Pitch (mm) | 1.89 |
| Module Resolution (WxH) | 160 x 90 |
| Module Dimensions (WxH, mm) | 302.4 x 170.1 |
| Weight per Module (kg) | 0.52 |
| No. of Modules per Unit Case (WxH) | 2 x 2 |
| Unit Case Resolution (WxH) | 320 x 180 |
| Unit Case Dimensions (WxHxD, mm) | 604.8 x 340.2 x 72.5 |
| Unit Case Surface Area (m2) | 0.206 |
| Weight per Unit Case (kg/unit) | 5.2 |
| Weight per Square Meter (kg/m2) | 25.3 |
| Physical Pixel Density (pixels/m2) | 279,947 |
| Unit Case Material | Die Casting Magnesium |
| Service Access | Front |
| Optical Specifications | |
| Min. Brightness (After Calibration) | 600cd/m2 |
| Color Temperature | 3,000 - 10,000 |
| Visual Viewing Angle (HxV) | 160 x 140 |
| Brightness Uniformity | 97% |
| Color Uniformity | ±0.003Cx,Cy |
| Contrast Ratio | 7,000 |
| Processing Depth (bit) | 16 |
| Electrical Specifications | |
| Power Consumption (W/Unit, Max.) | 180 |
| Power Consumption (W/Unit, Avg.) | 54 |
| Power Consumption (W/m2, Max.) | 874 |
| Power Supply (V) | 100 to 240 |
| Frame Rate (Hz) | 50 / 60 |
| Refresh Rate (Hz) | 3,000 |
| Operation Specifications | |
| Lifetime (Half Brightness, hrs)* | 100,000 |
| Operating Temperature | -10°C to +40°C |
| Operating Humidity | 10 - 80% RH |
| Certification | |
| Certification | IEC 60950-1 / EN 60950-1 / UL 60950-1, FCC Class A / CE / KC |
| Environment | |
| Environment | RoHS |
*The Lifetime(Half brightness) spec is subject to LED package spec
Views:
Documentation:
Download the lg las fine-pitch series datasheet (.pdf)
