LG 49LV340C
49" Class Essential Commercial TV Functionality
Sorry, this product is no longer available, please contact us for a replacement.
Click here to jump to more pricing!
Please Note: All Prices are Inclusive of GST
Overview:
The LG 340C TV has been specifically designed for various business environments. With simple user-friendly interfaces and superb images and video, the LV340C series helps drive messages and images between businesses and their target audiences. Also, the LV340C series supports WOL (Wake on LAN) and SuperSignTM C , helping management, engineers and IT departments remotely manage and efficiently control the LV340C.
- Size: 49"
- Public Display Mode
- USB Cloning
- USB Auto Playback +
- RS-232C
- WOL(Wake on LAN)
- Crestron Connected Certification
Features:
Key Features
Public Display Mode
From channel selection to volume level, you can control the
TV settings in public areas. Public Display Mode also
enables you to restore default settings, as required, on the
TVs.
RS-232C Control
Via the TV's RS-232C port, you can remotely control power
and volume settings simultaneously.
WOL (Wake on LAN)
WOL (Wake on LAN) helps you remotely turn on TVs over the
internet. Connect TVs and a PC in the same network, and send
Magic Packet program to the MAC addresses of registered TVs.
Then, it will wake up the TVs via LAN port.
Simple & Effective Maintenance
USB Cloning
Clone your LV340C's with efficiency and ease. The USB
Cloning feature allows you to simply copy the TV settings to
all the LV340C's using a USB memory device (sold
separately).
Lock Mode
Lock Mode blocks external input signals with non-compliant
content. This is a useful feature for preventing misuse of
TVs in various facilities or public spaces.
Self Diagnosis
Self Diagnosis enables engineers and IT to engineers to
analyze the data and identify technical issues quickly and
easily through a USB memory device.
Convenience & Entertainment
USB Auto Playback+
Create a media playlist of your choosing (video, music,
and/or images) via USB Auto Playback+. Save it to a USB
memory device, and then simply connect the USB memory device
to the TV to stream your playlist sequentially.
SuperSign C
With SuperSign C, LG's signage management software, you can
control and remotely monitor via the LAN port
Welcome Screen (Splash Image)
Display a customized greeting message with your business
name/logo on the TV when it is turned on.
Specifications:
| 49LV340C Specifications | |
|---|---|
| Display | |
| Screen Size | 49" |
| Diagonal Size | 48.5" |
| Type | Direct LED |
| Resolution | 1,920 x 1,080 (FHD) |
| Brightness | 400cd/m2 |
| Viewing Angle (H x V) | 178° / 178° |
| Response Time (G to G, ms) | 9 |
| Frame Rate | 60 Hz |
| Broadcasting System | |
| Analog | NTSC |
| Digital | ATSC / VSB / Clear QAM |
| Video | |
| Triple XD Engine | Yes |
| Real Cinema 24p (3:3 Pull down) | Yes |
| Dynamic Color Enhancer | Yes |
| Aspect Ratio | 6 modes (16:9, Just scan, Set by program, 4:3, Zoom, Cinema Zoom 1) |
| Audio | |
| Audio Output | 10W + 10W |
| Speaker System | 2.0 ch |
| Sound Mode | 6 modes (Standard, News, Music, Cinema, Sport, Game) |
| Optical Sound Sync | Yes |
| Clear Voice | Yes |
| General Features | |
| Installation | USB Cloning |
| Management | WOL (Wake On LAN), SNMP, USB Diagnostics, Multi IR Code, HTNG/HDMI-CEC |
| USB | USB Auto playback+, Moving Picture Playback (.asf, .wmv, .divx, .avi, .mp4, .m4v, .mov, .mpg, .mpeg, .mpe, etc.), Picture (jpeg, jpg, jpe, BMP, PNG), Audio Codec (MP3, AAC, M4A, WMA, WMA 10 pro, OGG) |
| Setting Option | Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care |
| Hospitality Features | |
| Hospitality Features | PDM (Public Display Mode), Lock Mode, Welcome Screen (Splash Image), Insert Image, External Speaker Out, RJP Compatibility, Crestron Connected Certified, Time Scheduler |
| Interface | |
| Set Side | HDMI In, USB 2.0 |
| Set Rear | RF In, AV In (Sharing with Component In), Component In + Video, Optical Video Audio Out, HDMI/HDCP In, RGB In, PC Audio Input (Sharing with Component Audio), RS-232C In, RJ45 (SNMP), External Speaker Out |
| Dimension | |
| Bezel Width (L / R, U, B) : on bezel based (mm) | 10, 10, 15.2 |
| Bezel Width (L / R, U, B) : off bezel based (mm) | 8.5, 8.5, 13.7 |
| Vesa (mm) | 300 x 300 |
| W x H x D / weight (with stand) | 43.6" x 27.6" x 9.3" / 25.2lb |
| W x H x D / weight (Carton) | 47.0" x 30.3" x 6.2" / 29.8lb |
| Power | |
| Voltage, Hz | 100 ~ 240V, 50/60Hz |
| Typical (Watts) | 37.0 |
| Stand-by (Watts) | 0.5 |
| Standard Approval | |
| Safety | UL |
| Environment | FCC |
| Etc. | RoHS, UL, NOM |
* Specifications are subject to change without notice, so please reach LG salesteam to ensure before order.
Views:
Documentation:
Download the LG Essential Commercial TV Functionality - LV340C Series Datasheet (.PDF)
